Bel Canto Black ACI 600 Reference Integrated Amplifier - High-End Audio System for Home Theater & Audiophile Listening (Demo Available)
Bel Canto Black ACI 600 Reference Integrated Amplifier - High-End Audio System for Home Theater & Audiophile Listening (Demo Available)Bel Canto Black ACI 600 Reference Integrated Amplifier - High-End Audio System for Home Theater & Audiophile Listening (Demo Available)

Bel Canto Black ACI 600 Reference Integrated Amplifier - High-End Audio System for Home Theater & Audiophile Listening (Demo Available)

$16499.45 $29999 -45%

Delivery & Return:Free shipping on all orders over $50

Estimated Delivery:7-15 days international

People:25 people viewing this product right now!

Easy Returns:Enjoy hassle-free returns within 30 days!

Payment:Secure checkout

SKU:97138096

Guranteed safe checkout
amex
paypal
discover
mastercard
visa

Product Description

Items marked (available to demo) are available in our store for audition. Please give us a call or email in advance for an appointment.

AVAILABLE IN BLACK ONLY
A TRUE ALL IN ONE REFERENCE.. PRE/AMP/DAC/STREAMER/PHONO

The Black Integrated refines the elements of the three chassis Black system into one beautifully constructed component. The ACI 600, with its modern look and feel, is the perfect all-in-one solution for the most critical listener. The reveals the subtlest intonations of voice and instrument together with the power and emotion recorded in the music you enjoy.

The ACI 600’s advanced integrated platform expands the way you live with your audio. The ACI 600 suite of options focuses on the core technologies of our high dynamic range DAC, precision volume and system control, ethernet streaming, programmable phono stage and headphone technologies, powered by ultra-low noise amplification for the ultimate all-in-one high performance solution.

The ACI 600 is designed to manage the complexity of all audio source and control functions with ease and efficiency. The volume and system functions are controlled by manually pressing and rotating the control dial on the top of the unit, or by using the IR custom remote control, or with your iPhone/iPad and the custom iOS app. The fully programmable display is easy to read and illuminates system status indicating source and volume. It also displays all programming functions and serves as the streaming display for meta data.

All source inputs are asynchronously re-clocked into the fully balanced advanced segment DAC measuring below 0.0005% distortion and 127dB of dynamic range. By stripping away the source clock and using Bel Canto’s custom ULN master clock circuitry we significantly reduces both jitter and distortion preserving the delicate audio signals from all sources.

Asynchronous ethernet connects you to the most compelling and power musical source available today. Bel Canto’s proprietary asynchronous ethernet and USB-A inputs provide the highest level of performance for high resolution files up to 24bits at 192ks/s, , and DSD64. This allows you to connect to a variety of subscription streaming service or source from your personal library that is stored on a NAS (networked attached storage) drive, or a multi-terabyte independent drive to the USB-A all providing full server function with complete iOS wireless control using our SEEK control App.

Asynchronous Digital SPDIF AES, RCA and Toslink inputs all operate at 24/192Ks.

Asynchronous USB2.0 Audio is compatible with any PCM source up to 24/348, , and DSD 128 (DoP). . USB2.0 works natively in OSX.

Inputs:

24bit Data to 192ks/s:AES, SPDIF, TOSLINK
24bit Data to 192ks/s, , and DSD64:10/100 Ethernet
24bits to 384ks/s, , and DSD64/128 (DoP):USB2 Audio

Low Level Outputs:

Line Level Analog:4.5Vrms with Bass Management
Headphone:4.5Vrms maximum, 32ohm minimum load

MM/MC Input:

MM:2.5mV to 5mV; 47K ohms
MC:0.25mV to 0.5mV; 50, 100, 500, 1k
RIAA Accuracy:+/- 0.25dB, 50Hz-15kHz
THD+N:<0.01% 1kHz A-Weighted
SNR:>70dB A-Weighted

Line Inputs:

Maximum Input:2.2 Vrms RCA
Input Impedance:10k ohms RCA
THD+N:0.003%, 1kHz
Dynamic Range:110dB, A-weighted 20Hz-20kHz

Loudspeaker Output:

Maximum Power Output:600W-4ohm, 300W-8ohm
Minimum Load:2 ohms
Peak Output Current:27 amperes
Frequency Response:-3 dB 0.5Hz-50kHz, all loads
Output connections:2-pair WBT Nextgen binding posts

Performance:

Dynamic Range:127dB A-weighted
THD+N:<0.001% 1W, 1kHz, 4 ohms
IMD (CCIF):<0.001%, 1W, 18.5:19.5kHz 1:1, 4 ohms

General:

Power Usage On:42W
Power Usage Off:0W
Internally Set Operating Voltages:100-120VAC, 220-240VAC 50/60 Hz
Dimensions:19" W x 14" D x 3.8" H (483 mm x 356 mm x 97 mm)
Weight:45lbs. (20.5 kg)

Features and specifications are subject to improvements and changes without prior notice.
